BIM Models

LOD 250

Volumetric model of residential projects used mainly for visual coordination of multiple specialities designs and 2D plans/ sections export

LOD 350

Loyal graphic modelling of a residential project aimed at production of marketing and reference images, as well as further budget and resources management over 4D planning.

LOD 400

As built models developed for high accuracy during the construction phase. These models were loaded with a highly precise information on small elements, from structure elements´ specifications to envelope elements calculations and specifications required under the FBC (Florida Building requirements)

Gallery
